PRODUCTION SPECIFICATION
Beurslanyards 2026
Fire Safety & Security — Brabanthallen Den Bosch — Stand B.21
CAMPAIGN CONCEPT
Beursthema
Reference Photos
Previous trade show lanyard set and hardware reference for factory.
Product Overview
VARIANT A
Phone Crossbody Lanyard
| Strap | 25mm polyester sublimation, 150-160cm adjustable |
| Snap hook | Heavy duty swivel, 360° rotation, matte black metal |
| Keyring | Extra keyring attachment |
| Phone patch | Universal TPU flat insert tab, white, 0.5mm |
| Safety | Breakaway buckle at neck |
VARIANT B
Badge / Keychain Lanyard
| Strap | 25mm polyester sublimation, ~90cm standard length |
| Lobster hook | Metal lobster claw clasp, matte black |
| Keyring | Split ring attachment |
| Badge clip | Crocodile badge clip |
| Safety | Breakaway buckle at neck |
Strap Specification
| Property | Value |
|---|---|
| Width | 25 mm (±0.5mm) |
| Material | Woven polyester — premium feel, not thin |
| Print method | Full dye-sublimation, double-sided |
| Length (phone crossbody) | 150–160 cm (adjustable with slider) |
| Length (badge/keychain) | ~90 cm (standard lanyard length) |
| Base color | SignaalBewaking Red — #C41E24 / Pantone 200 C |
| Print color | White |
| Repeat interval | 14 cm (140mm) |
| Total quantity | 2,500 straps (same design for both variants) |
Strap Print Pattern
The strap features the SignaalBewaking logo and payoff in a repeating pattern every 140mm. Both sides printed identically. The logo image file (PNG) is included in the artwork package.
This is the official SignaalBewaking logo. The white-on-transparent PNG version is included in the artwork package for production use. The logo must be printed clearly at 25mm strap width.
Hardware Specification
All metal hardware must be zinc alloy, minimum 2mm wall thickness, matte black finish. Must safely support a 200-250g smartphone with minimum 3kg pull force.
PHONE VERSION — 1,500 pcs
| Snap hook | Heavy-duty swivel, 360°, zinc alloy ≥2mm |
| Breakaway | Safety release buckle at neck |
| Slider | Length adjuster (150-160cm range) |
| Keyring | Extra split ring attachment |
| Phone tab | TPU flat insert, D-ring loop |
| Finish | Matte black (all hardware) |
BADGE VERSION — 1,000 pcs
| Lobster hook | Metal claw clasp, zinc alloy ≥2mm |
| Breakaway | Safety release buckle at neck |
| Keyring | Split ring attachment |
| Badge clip | Crocodile clip for ID badges |
| Finish | Matte black (all hardware) |
Phone Insert Tab
Universal flat tab that slides through the charging port cutout of any standard phone case.
Phone Attachment — How It Works
The phone tether tab connects your smartphone to the lanyard. No tools required. Works with any phone case that has a charging port cutout.
Remove Phone from Case
Take your phone out of the case. Place the flat TPU tab on the inside back of the case, with the tongue pointing down toward the charging port cutout.
Slide Tab Through Port
Push the narrow tongue (10mm) through the charging port slot at the bottom of the case. The D-ring should stick out below the case. The flat tab body stays inside.
Put Phone Back & Attach Cord
Place your phone back into the case — it presses the tab flat. Clip the lanyard cord to the D-ring. Done! Your phone hangs securely. Charging still works.
Color Specification
SignaalBewaking Red
| HEX | #C41E24 |
| Pantone | 200 C |
| CMYK | C5 M100 Y95 K2 |
| RGB | 196, 30, 36 |
White (print)
| HEX | #FFFFFF |
| Use | Strap text, tab base |
Packaging
PER LANYARD
OPP Bag
| Per lanyard | Clear OPP bag, sealed |
| Contents phone | 1 strap + hardware + phone tab + marketing card |
| Contents badge | 1 strap + hardware + badge clip + marketing card |
OUTER PACKAGING
Master Cartons
| Total outer boxes | 4-5 master cartons |
| Max weight | 20 kg per carton |
| Phone variant | ~2-3 cartons (1,500 pcs) |
| Badge variant | ~2 cartons (1,000 pcs) |
| Carton strength | Double-wall corrugated, air freight rated |
| Requirement | Detail |
|---|---|
| Carton marking | Clearly mark PHONE or BADGE variant on outside |
| Individual packaging | Each lanyard set in clear OPP bag, sealed |
| Ship to | Vendelier 71, 3905 PD Veenendaal, Netherlands Attn: Michiel van der Wal |
| Method | DDP air freight — max 20 kg per carton |
Factory Instructions
| Instruction | Detail |
|---|---|
| Color matching | Pantone 200 C — provide dye-sub test swatch before full production |
| Logo | Use the provided PNG logo file. Do NOT redraw or recreate the logo. |
| Logo quality | Logo must be crisp and fully readable at 25mm strap width. Test print required. |
| Hardware | All metal parts zinc alloy, ≥2mm thickness, matte black. Must support 250g phone. |
| Phone tab | TPU 0.5mm, must fit through standard USB-C port cutout. ≥3kg pull strength. |
| QC photos | Send photos of finished first batch before shipping entire order. |
| Shipping | DDP air freight to Netherlands. Include packing list + commercial invoice. |
| Ship to | Vendelier 71, 3905 PD Veenendaal, Netherlands Attn: Michiel van der Wal |
| Outer boxes | 4-5 master cartons, max 20 kg each. Double-wall corrugated. |
Production Files — Downloads
All artwork and specification documents for production. Each file includes the official SignaalBewaking logo.
Logo Files
Official Logo (JPG)
The official SignaalBewaking logo on red background. Use as visual reference for all production elements. White text, white border, red gradient background.
Logo — White on Transparent (PNG)
White logo on transparent background. For use on dark or colored surfaces — straps, packaging, marketing materials. High resolution (3899×1876px).
Lanyard Artwork — Logo + Tagline (PNG)
SignaalBewaking logo met tagline “Altijd verbonden met veiligheid” in wit op transparante achtergrond. Voor bedrukking lanyards. Hoge resolutie (3600×2689px).
Strap Artwork
Lanyard Strap — Full Length Preview
Shows how the repeat pattern looks across the full strap length (~1,550mm = 10-11 repeats). Use to verify pattern continuity and spacing.
Phone Insert Tab
Marketing Card (90×130mm)
Documents
EN
ZH
Quote Request / Offerteaanvraag / 报价请求
Complete quote request document for suppliers — available in Dutch, English, and Chinese. Includes all specifications, timeline, QC requirements, and shipping address.
Production Specification
Complete technical specification document with all measurements, materials, colors, and requirements.
Complete Package (ZIP)
All artwork files (SVG + PDF), logo files (JPG + PNG), quote requests (3 languages), and specification documents in one download.
